MAHA BAT

MAHABAT SAN OPzS BATTERIES

CONSTRUCTIONAL FEATURES

Specially mixed selenium lead alloy used for plate grid casting in pressure die casting
Low Antinomy [<3%] Positive alloy.
Plastic encapusaled Nut,Bolt on terminals.
Lead Coated Copper inter-cell connectors.
Micropourous Vent Plugs
Nomial Voltage :2V

BENEFITS

Cell connectors, Terminal having less corrosion
Easy monitoring through transparent SAN Transparent containers any malfunction at any stage.
Minimum maintenance :topping up very less.
Sutaible for enviroment conditions

Recommended Floating Recharge

Recommended Floating Recharge
Temperature	Float Voltage
<5 °C	2.25+0.02 VPC
5 °C-35 °C	2.23+0.02 VPC
36 °C-45 °C	2.20+0.02 VPC

SAN OPzS MAHABAT BATTERIES

Type	Rate Voltage (V)	Rated Capacity 10hr(Ah)		Dimentions mm				(±5%) Weight kg
		10h	1h	Dimentions mm
		Final Voltage 1.80V	Final Voltage 1.75V	Lenth	Width	Height	T.Height
OPzS 100	2	100	50	104	207	356	409	13.3
OPzS 200	2	200	90	104				17
OPzS 250	2	250	112.5	125				20.5
OPzS 300	2	300	135	146				24
OPzS 350	2	350	157.5	125		472	525	29
OPzS 400	2	400	189	146				34
OPzS 500	2	500	220.5	167				39
OPzS 600	2	600	270	146		647	700	47
OPzS 800	2	800	360	191	211			64
OPzS 1000	2	1000	450	234				78
12OPzS 1200	2	1200	540	276				92
12OPzS 1500	2	1500	675	276		798	851	115
16OPzS 2000	2	2000	399	399	210	772	827	150
20OPzS 2500	2	2500	487	487	212	772	827	185
24OPzS 3000	2	3000	576	576	212	772	827	220
